B101AW03 V0 10.1″ a-Si TFT-LCD Panel for AUO
$53,00
| Weight | 1 kg |
|---|---|
| MPN | |
| Brand |
AUO |
| Resolution | |
| Contrast Ratio | |
| Input Voltage | |
| Lcd Size |
Description
| Brand: | AUO |
| Panel Type: | a-Si TFT-LCDPanel |
| Panel Size: | 10.1″ |
| Resolution: | 1024(RGB)¡Á600 (WSVGA) |
| Display Mode: | TN, Normally White, Transmissive |
| Contrast Ratio: | 400 : 1 (Typ.) (Transmissive) |
| Surface: | Glare (Haze 0%), Hard coating (3H) |
| Brightness: | 200 cd/m2 (Typ.) |
| Display Colors: | 262K (6-bit) |
| Viewing Angle: | 45/45/15/35 (Typ.)(CR?10) (L/R/U/D) |
| Frequency: | 60Hz |
| Lamp Type: | WLED |
| Signal Interface: | LVDS (1 ch, 6-bit) |
| Input Voltage: | 3.3V (Typ.) |
| Response Time: | 16 (Typ.)(Tr+Td) (ms) |
