P1210XGF1MB00 Tianma LCD panel replacement
$57,00
| Weight | 1 kg |
|---|---|
| MPN | |
| Brand |
Tianma |
| Resolution |
Description
| product_name: | P1210XGF1MB00 12.1″ 1024×768 LCD Panel for Tianma |
| Brand: | Tianma |
| Panel model: | P1210XGF1MB00 |
| Panel Size: | 12.1 |
| Resolution: | 1024×768 |
| Backlighting: | WLED |
| Interface: | LVDS |
| Brightness: | 500 |
| Frequency: | 60Hz |
| Active Area: | 245.76×184.32 |
| TN/VA/IPS: | SFT |
| C/R: | 1000:1 |
| View Angle: | 88/88/88/88 |
| Colors: | 262K/16.7M |
| Typ. Depth: | 8.3mm |
| Max. Depth: | 10mm |
| Pins: | 20 pins |
| Work Temp.: | -30~80°C |
| Storage Temp.: | -40~90°C |
| Outline Size: | 260.5×203 |
